Applies to: E5

Exchanging the system module locking bolt

The locking bolt for the system module is fixed with a nut.

  1. Have ready:

    • 1 x Spare locking bolt



    • 1 x 8 mm open-end wrench

      •

  2. Remove the lower service cover and the system module.

    Exchanging the system module

  3. Loosen the nut with the open-end wrench.

  4. Remove the locking bolt.

  5. Insert the spare locking bolt into the opening and tighten it with the nut.

    6.





  6. Install the system module and the lower service cover.

    Exchanging the system module
